Capacity (Liters) 5.0
Inner Diameter (mm) 150
Overall height (mm) 405
Weight (kg) 6.3
Certification
ASME Section VIII-01, Div. 1
Directive 2014/68/EU Article 4
Clause 3
For group 2 liquids
Material Wetted parts 303 stainless steel & Clear
Acrylic or Toughened glass cylinder
Shell Cylindrical
Working Rated Pressure 0 to 4 bar at from 0°C to 38°C
Working Rated Vacuum 0 to -1 bar at from 0°C to 38°C
Closure 3 plastic star grips 4 plastic star grips
Closure seal Viton O-ring
Top & Bottom Seals Viton
Internal/External finish Machined
