Capacity1.0 liter
Dimensions100 mm inside diameter,
235 mm overall height, 2.8 kg empty
CertificationASME Section VIII-01, Div. 1
Directive 2014/68/EU Article 4 Clause 3
For group 2 liquids
MaterialWetted parts 303/304 stainless steel
ShellCylindrical
Working Rated Pressure0 to 6.9 bar at 38°C
Working Rated Vacuum0 to -1 bar at from 0°C to 38°C
Closure2 stainless steel swing bolts and
black plastic star grips
Closure sealViton O-ring
Internal finishBrushed, welds as welded
External finishBrushed, welds as welded
Minimum speed30rpm
Maximum speed450rpm
Speed under load235rpm
Air consumption5.3L/s
Torque10Nm
MixerStainless steel shaft and single blade Impeller
OptionAlternative mixing element
Lubricating filter/regulator
