Range of section thickness setting:
0.5-100 μm
0.5-2μm increment 0.5μm
2-10μm increment 1μm
10-20μm increment 2μm
20-100μm increment 5μm
Range of trimming setting: 1-600μm
1-10μm increment 1μm
10-20μm increment 2μm
20-100μm increment 10μm
100-600μm increment 50μm
Specimen horizonal feeding:26mm
Range of specimen retraction:20μm
Specimen clamp can be 360°turned
Minimum setting thickness of slice:0.5μm
Maximum size of slicing:50 x 50mm
Precision error:±1%
Voltage: AC220V 50Hz or 110V 60Hz
Power: 150W
Weight : 32kg
