Section Thickness Setting Range: 0 - 60μm
Trimming Thickness Setting Range: 0 - 100μm
Section thickness adjustment:
0 - 1μmincrement 0.25μm
1 - 10μm increment 1μm
10 - 20μm increment 2μm
20 - 60μm increment 5μm
Total Horizontal Specimen Feed:26 mm
Vertical Specimen Stroke: 52 mm
Specimen Clamp Rotation: any angle within 360 degrees
Specimen Orientation: XY – 8°
Automatic return of specimen
Minimum Setting of Sectioning Thickness: 0.25μm
Maximum Specimen Size:50×50mm
Precision Error: ±1%
Working Voltage: AC 220V±10% 50Hz (standard model); AC110V±10% 60Hz
Power: 150W
Dimensions: 585×410×300mm(W×D×H)
Net weight: 28kg
