Work mode: Infuse,withdraw,infuse /withdraw,withdraw/infuse,continuous mode
Number of channel: 2
Stroke of pump: 110mm
Advance per microstep: 0.156μm/μstep
Linear speed: 1μm/min~150mm/min
Syringe size: 10μL~60mL
Flow rate: 0.184nL/min~83.318mL/min
Max rated linear force: >16kgf
Thrust regulation: 25%~100% arbitrary adjustable
Accuracy: Error<±0.35%,(>30% of pump stroke)
Display: 5-inch color LCD screen display and transfusion volume, residual fluid volume, flow ,operation direction ,
syringe specification, etc. Animation display operation
Operation mode: Touch screen + button
Power-off memory: Storing the running parameters automatically
Function: Pause and stop, the sound tip, the lock parameters, fast forward and retreat quickly ,display brightness adjustment
Communication interface: RS485 communication interface, MODBUS protocol,Wi-Fi function(optional)
Dimension mm(L×W×H): 240×196×125
Weight: 2.95kg
Power supply: AC100~240V，50/60Hz
IP grade: IP31
