■Bottle amount : 12. 1 - 9 for dehydration reagent, 14 - 16 for cleaning agent
■Nos of Reagent Station: 12
■Tissue Processing Station: NO.1 to No.9 Station
■Washing Station: No.14 to No.16 Station
■Nos of Wax Tank: 3(No.10,12 and 13)
■Nos of Working Station: 1
■Capacity of Processing Station: 9Liters
■Capacity of Reagent Station :6L
■Temp.of Processing Station:
■Medium is the solvent: ≤45℃
■Medium is the Wax: 58℃-70℃
■Operation pressure:<0.1Mpa
■Wax temperature :58℃-70℃
■Wax melt time not more than 3 hours
■Power input:<1500VA+10%
■Time for immerse: 0 - 99 hours 59 minutes
■Working Voltage:220VAC±10%,50/60HZ
■Time for Inflow Liquid: no more than 5Min
■Time for Exclude Liquid: no more than 5Min
■Stirring time:set randomly
■Interval time for Stirring: set randomly
■Operation mode: manual and automatic
Gross Weight: 200kgs;
-Dimension: 750 x 750 x 1460mm.
